92
5-15. ANC IN STATUS 1-2
ANC IN STATUS1 655
DID/SDID: **/**
S334-1CDP(708)
S352M VPID
-----
Displays the status of ancillary data packets in an input SDI signal.
Displays the detected DID and SDID of the ancillary data in hexadecimal format, such as
DID/SDID: 15/30, if they are different from that of supported formats.
Displays the ancillary data name, such as S334-1CDP(708), if the DID and SDID of the ancillary
data match that of supported formats.
See section 19. “FA-9500 Ancillary Data Packet Name List” for details on ancillary data names,
and DID and SDID of formats.
The status of up to 8 ancillary data can be displayed.
5-16. CONV1 ANC OUT
CONV1 ANC OUT 671
CEA608:PRESENT L: 21
WSS:ABSENT
VI:PRESENT L:14/277
Displays the status of CEA608, WSS, and VI ancillary data inserted into luminance signal of
CONV 1 output.
The line number in which the ancillary data is in is displayed.
Displays PRESENT if ancillary data is inserted. Displays ABSENT if no anceillary data is inserted.
If ANC MODE is set to H/V ANC, the state of the V ANC setting (PASS or BLANK) will be
displayed. In such case, no line number will be displayed. (See section 5-10-9 CONV1 ANC SET
for details on ANC MODE and V ANC setting.)
5-16-1. CONV1 S2016 OUT
Displays whether the S2016-3 ancillary data is inserted into CONV 1 output video signal.
When no S2016-3 is in the CONV1 output video signal
CONV1 S2016 OUT 672
S2016-3:ABSENT
If ANC MODE in 5-10-9 CONV1 ANC SET is set to H/V ANC, the state of the V ANC setting
(PASS or BLANK) is displayed.
When S2016-3 is in the CONV1 output video signal
CONV1 S2016 OUT 672
S2016-3:PRESENT
AFD:02 AR:0
4:3 L 16:9T
D:10000000 00000000
AFD: Active Format Description is displayed in hexadecimal format.
AR: Aspect Ratio is displayed in binary format (0=4:3, 1=16:9)
The detected AFD type is shown on the third row.
D: Detected Data1-8 are displayed in hexadecimal format.
See section 20-6 “AFD Code Abbreviations” for details on AFD types.
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
To Next Page
