FOR-A FA-9500 - Aspect Ratio Conversion with AFD

261
20-2. Aspect Ratio Conversion with AFD
 4:3 to 16:9 conversion
Input AFD
(WSS)
Input AFD
(VI, S2016)
Illustration in a 4:3
coded frame
SD: AFD (16:9) conv.
HD: AFD conversion
SD: AFD-ALT(16:9) conv.
HD: AFD-ALT conversion
BOX 16:9 TOP
4:3 L 16:9 T
BOX 14:9 TOP
4:3 L 14:9 T
BOX 16:9 CTR
4:3 L> 16:9
F 4:3
4:3 F 4:3
BOX 16:9 CTR
4:3L16:9PRTD
BOX 14:9 CTR
4:3 L 14:9
F 14:9 CTR
PRTD
4:3 F ALT14:9
None
4:3 L ALT 14:9
None
4:3 L ALT 4:3
