6. AUDIO Settings
Make the menu buttons light up orange using the VIDEO/AUDIO button.
(Pressing the button while the buttons are lit green turns the lights orange.)
Afterwards, the audio menus displayed on the lower row on each menu button
can be selected.
6-1. SDI AUDIO Settings (SDI AUDIO)
Allows you to set the SDI IN1/2, SDI OUT1/2, and SDI OUT3/4 embedded audio signals.
6-1-1. SDI AUDIO GAIN
SDI AUDIO GAIN 121
CH SEL :CH1
GAIN SET: 0.0dB
MASTER : 0.0dB
Parameter Default
Setting range
(Steps)
Description
CH SEL CH1 CH1 - CH16
Selects a channel for which to
adjust the gain.
GAIN SET 0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
*1
Sets the input gain for the SDI
embedded audio channel that is
selected under CH SEL.
MASTER 0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
Sets the offset to the input gain for
all channels CH1 to CH16 of
SDI-embedded audio.
*1 The total value of GAIN SET and MASTER should not exceed the setting range. If the
range is exceeded, the alert will be displayed as *20.0 dB or *-20.0 dB.
Menu button
PROCESS
SDI AUDIO
Menu button
VIDEO
AUDIO
