117
6-9-3. Dolby DECODER REFERENCE
* This menu is available only if the FA-95D-D option is installed.
Dolby DEC REF 303
INPUT :AUX REF IN
Parameter Default Setting range Description
INPUT AUX REF IN
OUTPUT VIDEO
AUX REF IN
INPUT VIDEO
Selects a reference signal to be used in the
Dolby decoder. PCM signal output from the
Dolby decoder will be synchronized to the
selected reference signal.
OUTPUT VIDEO: Uses the output video
signal.
AUX REF IN: Uses the input signal in the
optional Dolby reference input connector
(REF IN). If no signal is in the REF IN
connector, the PCM signal output will be in
free-run mode.
INPUT VIDEO: Uses the input video signal
as a reference signal.
6-9-4. Dolby DOWNMIX
* This menu is available only if FA-95D-D option is installed.
Dolby DOWNMIX 304
MODE:SURROUND
Parameter Default Setting range Description
MODE SURROUND
SURROUND
STEREO
MONAURAL
Selects a downmix mode for the Dolby
decoder.
6-9-5. Dolby DECODER GAIN
* Menu is available only if the FA-95D-D option is installed.
Dolby DEC GAIN 305
CH SEL :DEC CH1
GAIN SET: 0.0dB
MASTER : 0.0dB
Parameter Default Setting range Description
CH SEL DEC CH1
DEC CH1 – CH8
DolbyDM-L
DolbyDM-R
Selects a signal for gain adjustment.
DEC CH1-CH8: Dolby-decoded PCM
signal
DolbyDM-L/R: Down mixed signal
generated from Dolby-decoded PCM
signal
GAIN SET 0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
*1
Sets gain for the signal selected under
CH SEL.
MASTER 0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
Sets offset for all Dolby-decoded
signals.
*1 If the MASTER setting exceeds the total setting range of individual channels, the alert will
be displayed as *20.0dB or *-20.0dB.
Menu button
VIDEO OP
AUDIO OP
Menu button
VIDEO OP
AUDIO OP
Menu button
VIDEO OP
AUDIO OP
