5-8-3. COMPOSITE SET
Allows you to assign video signals to output from the COMPOSITE video output connector.
COMPOSITE SET 74
ASSIGN:CONV1
525/60 >>525/60
Parameter Default
Setting range
(Steps)
Description
ASSIGN CONV1
CONV1
CONV2
Selects whether to output CONV1 or CONV2
signal from the COMPOSITE connector.
－ － －
The input signal format and COMPOSITE
output signal format are displayed on the third
row.
* If the assigned CONV1 or CONV2 signal is an HD signal, the COMPOSITE output will be a
black video. See the below Composite Output Format Table for details.
Composite Output Format Table
CONV1 and 2 output signals Output signal from COMPOSITE connector
525/60 CONV1,2 signals in 525/60
625/50 CONV1,2 signals in 625/50
1080/59i B.B. in 525/60
1080/50i B.B. in 625/50
1080/24PsF B.B. in 625/50
1080/23.98PsF B.B. in 525/60
720/59p B.B. in 525/60
720/50p B.B. in 625/50
1080/59p B.B. in 525/60
1080/50p B.B. in 625/50
