7-3. GPI SETTING
GPI SETTING 196
GPI1-7 SEL:GPI1
IN/OUT SEL:INPUT
ASSIGN:NONE
Parameter Default
Setting range
(Steps)
Description
GPI1-7 SEL GPI1 GPI1-7 Selects a GPI pin of the REMOTE port.
IN/OUT SEL
*1
INPUT
INPUT
OUTPUT
Selects whether to use the GPI pin that
is selected under GPI1-7 SEL for input
or tally output.
ASSIGN NONE
In case IN/OUT SEL is
set to INPUT
*2
NONE
BY-PASS
FREEZE
FULL CB
75% CB
SMPTE CB
RAMP
SDI1
SDI2
COMPOSITE
YPbPr SMPTE
*4
YPbPr BETACAM
*4
RGB
*4
Y/C
*4
DEFAULT
EVENT1 - 100
CHGOV ENABLE
*5
CHGOV DISABLE
*5
CONV1 KEYER
CONV2 KEYER
CONV1 LOAD 1 - 7
*6
CONV2 LOAD 1 - 7
*6
In case IN/OUT SEL is
set to OUTPUT
NONE
*3
FREEZE
*3
VIDEO IN
*3
AUDIO IN
*3
REF IN
*3
FAN ALARM
*3
DC POWER1
*3
DC POWER2
*3
SDI1
SDI2
COMPOSITE
YPbPr SMPTE
*4
YPbPr BETACAM
*4
RGB
*4
Y/C
*4
CHANGEOVER
*5
CHGOV ENABLE
*5
CONV1KEYER
CONV2KEYER
Assigns a function to the GPI pin that is
selected under GPI1-7 SEL according
to the selection under IN/OUT SEL.
LOGO ID 1 - 7 1 - 256
Selects a logo ID for the selected
CONV1 LOAD 1 - 7, or CONV2 LOAD 1
– 7.
*1 Whenever the IN/OUT SEL setting is changed, ASSIGN is reset to NONE. Reset ASSIGN.
*2 The input functions consist of pulse mode and level mode functions. See the following “◆
INPUT FUNCTION” for details.
