11-2. Digital Output Level Relative to the Analog Input Level
Digital Reference Level: -18dBFS
ANALOG IN LEVEL setting
Analog audio input level -10 dBm 0 dBm 4 dBm 8 dBm
-20 dBm -28 dBFS -38 dBFS -42 dBFS -46 dBFS
-10 dBm -18 dBFS -28 dBFS -32 dBFS -36 dBFS
-4 dBm -12 dBFS -22 dBFS -26 dBFS -30 dBFS
0 dBm -8 dBFS -18 dBFS -22 dBFS -26 dBFS
4 dBm -4 dBFS -14 dBFS -18 dBFS -22 dBFS
8 dBm 0 dBFS -10 dBFS -14 dBFS -18 dBFS
10 dBm CLIP -8 dBFS -12 dBFS -16 dBFS
Digital Reference Level: -20dBFS
ANALOG IN LEVEL setting
Analog audio input level -10 dBm 0 dBm 4 dBm 8 dBm
-20 dBm -30 dBFS -40 dBFS -44 dBFS -48 dBFS
-10 dBm -20 dBFS -30 dBFS -34 dBFS -38 dBFS
-4 dBm -14 dBFS -24 dBFS -28 dBFS -32 dBFS
0 dBm -10 dBFS -20 dBFS -24 dBFS -28 dBFS
4 dBm -6 dBFS -16 dBFS -20 dBFS -24 dBFS
8 dBm -2 dBFS -12 dBFS -16 dBFS -20 dBFS
10 dBm 0 dBFS -10 dBFS -14 dBFS -18 dBFS
Digital Reference Level: -24dBFS
ANALOG IN LEVEL setting
Analog audio input level -10 dBm 0 dBm 4 dBm 8dBm
-20 dBm -34 dBFS -44 dBFS -48 dBFS -52 dBFS
-10 dBm -24 dBFS -34 dBFS -38 dBFS -42 dBFS
-4 dBm -18 dBFS -28 dBFS -32 dBFS -36 dBFS
0 dBm -14 dBFS -24 dBFS -28 dBFS -32 dBFS
4 dBm -10 dBFS -20 dBFS -24 dBFS -28 dBFS
8 dBm -6 dBFS -16 dBFS -20 dBFS -24 dBFS
10 dBm -4 dBFS -14 dBFS -18 dBFS -22 dBFS

See REF LEVEL in section 6-10-2. "DIGITAL AUDIO" for details on the Digital
Reference Level settings.
See section 6-3-1. "ANALOG IN LEVEL" for details on the ANALOG IN LEVEL
settings.
