5-9-1-3. CONV2 LOGO SEL
Allows you to select a logo function mode for CONVERTER2.
CONV2 LOGO SEL 403
LOGO ID: 1
NAME:FOR A
LOGO FORMAT:HD 1080
CONV1:1080/59i
Parameter Default Setting range Description
LOGO ID 1 1-256 Selects a logo to be output to CONV 2 output.
NAME
*1
- -
Displays the registered name of the ID-selected
logo.
Displays “-----“ if the logo is not registered.
LOGO
FORMAT
*1
- -
Displays the format of the ID-selected logo.
Logo formats: SD 525, SD 625, HD 1080, HD
720
Displays “-----“ if the logo is not registered.
CONV2
*2
- -
Displays the video format of the Converter 2
output signal.
*1 NAME and LOGO FORMAT can be registered for each logo ID via FA-95LG GUI. See
the separate FA-95LG GUI Operation Manual for details.
*2 The video format displayed under CONV2 and the logo format displayed under LOGO
FORMAT must match. Otherwise no logo will be displayed even if KEYER in section
5-9-1-4 “CONV2 KEYER SET” is turned ON.
