18. About SNMP (Simple Network Management Protocol)
The FA-9500 can be remotely monitored and some of its settings can be remotely changed using
the SNMPv2C protocol. Some menu items can also be set via the network. MIB (Management
Information Base) is required for the monitoring and can be downloaded (see section 9-6-3
"Downloading a MIB File"). See section 9-8-3 "SNMP SETTING" for details about the SNMP
network settings.
 SET/GET List
○: Available －: Unavailable
Object group
Menu name in
FA-9500
Item name in
FA-9500
Description Object name in MIB file OID Type Write Read Trap
Trap event
(value)
OID: 1.3.6.1.4.1.20175.1.301.1. (Unit info)
Unit Info
－ Product Name Model Name fa95ProductName 1 OCTET STRING - ○ - -
－ Product Code Product Code fa95ProductCode 2 INTEGE
R
- ○ - -
－ Unit Name Unit Name fa95UnitName 3 OCTET STRING - ○ - -
－ Serial No. Serial No. fa95SerialNumbe
r
4 INTEGE
R
- ○ - -
Unit Ver.
Soft Software version fa95SoftVersion 11 OCTET STRING - ○ - -
FPGA1 Ve
r
FPGA1 version fa95FPGA1Version 12 OCTET STRING - ○ - -
FPGA2 Ve
r
FPGA2 version fa95FPGA2Version 13 OCTET STRING - ○ - -
FPGA3 Ve
r
FPGA3 version fa95FPGA3Version 14 OCTET STRING - ○ - -
OID:1.3.6.1.4.1.20175.1.301.1.100. (Software)
Soft Option
SOFT
OPTION1/2
FA-95SCNV
0: notInstalled
1: installed
fa95ScnvOption 1 INTEGER - ○ - -
FA-95AVO
0: notInstalled
1: installed
fa95AvoOption 2 INTEGER - ○ - -
FA-95-3G
0: notInstalled
1: installed
fa95-3GOption 3 INTEGER - ○ - -
FA-95CO
0: notInstalled
1: installed
fa95CoOption 4 INTEGER - ○ - -
FA-95LG
0: notInstalled
1: installed
fa95LGOption 5 INTEGER - ○ - -
OID:1.3.6.1.4.1.20175.1.301.1.200.1 (Option in Slot A)
OPTION Slot A OPTION A Ver
Name
0: notInstalled
1: FA-95AIO
4: FA-95DE-E
5: FA-95D-D
11: FA-95DACBL
12: Unknown
fa95SlotTypeA 1 INTEGER - ○ - -
FPGA1 Ve
r
SlotA FPGA1 version fa95FPGA1VerSlotA 2 OCTET STRING(5|13) - ○ - -
FPGA2 Ve
r
SlotA FPGA2 version fa95FPGA2VerSlot
A
3 OCTET STRING(5|13) - ○ - -
SOFT Ve
r
SlotA Sof version fa95CPUVerSlotA 4 OCTET STRING(5|13) - ○ - -
OID:1.3.6.1.4.1.20175.1.301.1.200.2 (Option in Slot B)
OPTION Slot B OPTION B Ver
Name
0: notInstalled
1: FA-95AIO
4: FA-95DE-E
5: FA-95D-D
11: FA-95DACBL
12: Unknown
fa95SlotTypeB 1 INTEGER
FPGA1 Ve
r
SlotB FPGA1 version fa95FPGA1VerSlotB 2 OCTET STRING(5|13)
FPGA2 Ve
r
SlotB FPGA2 version fa95FPGA2VerSlotB 3 OCTET STRING(5|13)
SOFT Ve
r
SlotB Soft version fa95CPUVerSlotB 4 OCTET STRING(5|13)
OID: 1.3.6.1.4.1.20175.1.301.2.2. (Input signal selection)
INPUT SEL
VIDEO IN
SETTING
Input Select
0: SDI1
1: SDI
2: Composite
3: YPbPr-SMPTE
4: YPbPr-BETACAM
5: RGB
6: YC
fa95VideoInputSelect 1 INTEGER ○ ○ - -
Video Loss Mode
If no signal is present:
0: Back Color
1: Auto Freeze
2: Color Bar
3: Output Disable
fa95VideoLossMode 2 INTEGER ○ ○ - -
OID: 1.3.6.1.4.1.20175.1.301.2.3 (Output selection)
OUT SEL
VIDEO OUT
MODE
Mode
0: Fi
x
1: Auto
fa95VideoOutMode 1 INTEGER ○ ○ - -
SD→UP
HD Format
0: 1080i
1: 720p
3: 1080PsF
4: 1080p(3G)
fa95UpConvertSDto 2 INTEGER ○ ○ - -
SDI 1/2 OUT
SET
Assign(Fix)
0: Converter 1
1: Converter 2
fa95OutSDI1-2FixedSel 11 INTEGER ○ ○ - -
Assign(Auto)
0: HD
1: SD
fa95OutSDI1-2AutoSel 12 INTEGER ○ ○ - -
SDI 3/4 OUT
SET
Assign(Fix)
0: Converter 1
1: Converter 2
fa95OutSDI3-4FixedSel 21 INTEGER ○ ○ - -
Assign(Auto)
0: HD
1: SD
fa95OutSDI3-4AutoSel 22 INTEGER ○ ○ - -
COMPOSITE
SET
Assign(Fix)
0: Converter 1
1: Converter 2
fa95OutVBSFixedSel 31 INTEGER ○ ○ - -
COMPOMEMT
SET
Assign(Fix)
0: Converter 1
1: Converter 2
fa95OutComponentFixedSel 41 INTEGER ○ ○ - -
Assign(Auto)
0: HD
1: SD
fa95OutComponentAutoSel 42 INTEGER ○ ○ - -
Mode
0: YPbP
r
-SMPTE
1: YPbPr-BETACAM
2: RGB
3: YC
fa95OutComponentOutMode 43 INTEGER ○ ○ - -
*1 FA-95AVO comes standard (optional in Japan).
