5-8-4. COMPONENT SET
Allows you to assign video signals to output from the FA-95AIO video output connectors.
Effective only if the FA-95AIO option is installed.
COMPONENT SET 75
ASSIGN:CONV1
525/60 >>1080/59i
OUTPUT:YPbPr SMPTE
Parameter Default Setting range Description
ASSIGN CONV1
CONV1
CONV2
Selects whether to output CONV1 or CONV2
signal from the ANALOG COMPONENT OUT
connector.
－ － －
The input signal format and analog component
output signal format are displayed on the third
row.
OUTPUT
YPbPr
SMPTE
YPbPr SMPTE
YPbPr BETACAM
RGB
Y/C
Selects a format for the analog component
output (FA-95AIO).
SMPTE and BETACAM are SD-SDI output
formats.
* The FA-95AIO connector outputs a black video if the output signal from the selected
CONV1 or CONV2 is 1080p and MODE is set to YPbPr or RGB. See the below
YPbPr/RGB Output Format table for details.
* The FA-95AIO connector outputs a black video if the output signal from the selected
CONV1 or CONV2 is an HD signal and MODE is set to Y/C. See the below Y/C Output
Format table for details.
YPbPr/RGB Output Format
CONV1 or 2 output signal FA-95AIO YPbPr/RGB
output signal
525/60 525/60 signal in CONV1 or 2
625/50 625/50 signal in CONV1 or 2
1080/59i 1080/59i signal in CONV1 or 2
1080/50i 1080/50i signal in CONV1 or 2
1080/24PsF 1080/24PsF signal in CONV1 or 2
1080/23.98PsF 1080/23.98PsF signal in CONV1
or 2
720/59p 720/59p signal in CONV1 or 2
720/50p 720/50p signal in CONV1 or 2
1080/59p 1080/59i black video
1080/50p 1080/50i black video
Y/C Output format
CONV1 or 2 output signal Y/C output signal
525/60 525/60 signal in CONV1 or 2
625/50 625/50 signal in CONV1 or 2
1080/59i 525/60 BB signal
1080/50i 625/50 BB signal
1080/24PsF 625/50 BB signal
1080/23.98PsF 525/60 BB signal
720/59p 525/60 BB signal
720/50p 625/50 BB signal
1080/59p 525/60 BB signal
1080/50p 625/50 BB signal
Menu button
OUT SEL
MODE
To Next Page
