160

9-2-9. Video Test Signal

Clicking block (9) on the video block diagram opens the Video Test Signal setting dialog box.

After completing the settings, click Close to close the dialog box.

Click Refresh to update the settings.

Parameter Default Setting range Description

Video Test Signal Off

Off

Full Color Bar

75％ Color Bar

SMPTE Color Bar

Ramp

Outputs an internal video test

signal.
