9-3-8. Audio Test Signal

Clicking block (10) on the audio block diagram opens the Audio Test Signal dialog box.

After completing the settings, click Close to close the dialog box.

Click Refresh to update the settings.

Parameter Default Setting range Description

Audio Test Signal Off

Off

1kHz Tone

Outputs an internal audio test signal
