FOR-A FA-9500 - Conv2 VI out; Conv2 Wss out

95
5-18-2. CONV2 VI OUT
Displays whether the RP186 VI ancillary data is inserted into CONV 2 output video signal.
 When no RP186 VI is in the CONV2 output video signal
CONV2 VI OUT 683
RP186 VI:ABSENT
 When RP186 VI is in the CONV2 output video signal
CONV2 VI OUT 683
RP186 VI:PRESENT
AFD:02 SS:02
BOX 16:9 TOP
D1:12 D2:02 D3:02
Displays the status of RP186 VI (Video Index) Class1.
AFD: Active Format Description is displayed in hexadecimal format.
SS: Scanning System is displayed in hexadecimal format.
The detected AFD type is shown on the third row.
D1-D3: Detected Data are displayed in hexadecimal format.


See section 20-6 “AFD Code Abbreviations” for details on AFD types.
5-18-3. CONV2 WSS OUT
Displays whether the BT1119 WSS ancillary data is inserted into CONV 1 output video signal.
 When no BT1119 WSS is in the CONV2 output video signal
CONV2 WSS OUT 684
BT1119 WSS:ABSENT
If ANC MODE in 5-10-10 CONV2 ANC SET is set to H/V ANC, the state of the V ANC setting
(PASS or BLANK) is displayed.
 When BT1119 WSS is in the CONV2 output video signal
CONV2 WSS OUT 684
BT1119 WSS： PRESENT
AFD:04
BOX 16:9 TOP
BIT13-0:0004
Displays the status of BT1119-2 WSS (Wide Screen Signalling).
AFD: Active Format Description is displayed in hexadecimal format.
The detected AFD type is shown on the third row.
BIT13-0: Detected Bits 13 – 0 are displayed in hexadecimal format.


See section 20-6 “AFD Code Abbreviations” for details on AFD types.
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
