9-2-2-1. About Scene Cut Detection and Frame Delay Settings
To properly perform AVO scene cut detection and adjustment, Frame Delay must be set in
the setting range according to the menu settings (9-2-3 “Frame Delay” menu) as shown in
the table below.
FRAME DELAY Setting Range Chart
*1
SYNCHRO
*2
Setting Rrange per Input Video Format
525/60i
625/50i
1080/59i
1080/50i
720/59p/50p
1080/59p,50p
1080/23PsF, 24PsF
FRAME 1 to 8 FRAME 2 to 8 FRAME
LINE/AVDL Cannot be set Cannot be set
INPUT 2 to 8 FRAME 3 to 8 FRAME
*1 Synchro Mode settings in section 9-4-1 “Video System”
*2 The current input video format can be verified in the Unit/Video Status menu (Sec.
9-7-1) for each input selected in the Video Input Setting menu (Sec. 9-2-1).
IMPORTANT
Adjust the audio delay as required in the Audio Output Delay menu (Sec. 9-3-5) to
account for any additional video signal delay produced by changing Frame Delay
settings in the Frame Delay menu (Sec. 9-2-3).
