FOR-A FA-9500 User Manual

89
5-13-12. SDI 3/4 OUT AUDIO
SDI3/4 OUT AUDIO 565
CH 1:PCM
CH 2:PCM
CH 3:PCM
CH 4:PCM
SDI3/4 OUT AUDIO 566
CH 5:PCM
CH 6:PCM
CH 7:PCM
CH 8:PCM
SDI3/4 OUT AUDIO 567
CH 9:PCM
CH10:PCM
CH11:PCM
CH12:PCM
SDI3/4 OUT AUDIO 568
CH13:PCM
CH14:PCM
CH15:PCM
CH16:PCM
Parameter Display Description
CH1 - CH16
PCM
SILENCE
NON-PCM
UNKNOWN
BLANK
BY-PASS
Displays the status of audio signal channels CH1
through CH16 of the SDI 3/4 output.
PCM: Normal audio signal
SILENCE: Mute signal
NON-PCM: Compressed audio data such as AC3
UNKNOWN: Unidentifiable
BLANK: No audio signal embedding
BY-PASS: By-passed through
5-13-13. AES OUT AUDIO
AES OUT AUDIO 569
CH 1:PCM
CH 2:PCM
CH 3:PCM
CH 4:PCM
AES OUT AUDIO 570
CH 5:PCM
CH 6:PCM
CH 7:PCM
CH 8:PCM
Parameter Display Description
CH1 - CH8
PCM
SILENCE
NON-PCM
UNKNOWN
INPUT SETTING
Displays the status of the audio signal output from the
DIGITAL AUDIO IO connectors.
PCM: Normal audio signal
SILENCE: Mute signal
NON-PCM: Compressed audio data such as AC3
UNKNOWN: Unidentifiable
INPUT SETTING: Connector is set to input
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
