FOR-A FA-9500 - 5-13-2. VIDEO IN STATUS

81
5-13-2. VIDEO IN STATUS
VIDEO IN STATUS 502
SDI1： 1080/59i
SDI2： 525/60
COMPOSITE:525/60
REFERENCE:525/60
Parameter Display Description
SDI1
LOSS
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
1080/59p
1080/50p
BY-PASS
UNKNOWN
Displays the video format of the SDI1 input signal.
Displays “LOSS” if there is no input signal.
Displays “UNKNOWN” if there is an unsupported input
signal.
SDI2
LOSS
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
1080/59p
1080/50p
BY-PASS
UNKNOWN
-----
Displays the video format of the SDI2 input signal.
Displays “LOSS” if there is no input signal.
Displays “UNKNOWN” if there is an unsupported input
signal.
Displays “-----“ if the FA-95AIO option is installed and
VIDEO INPUT SET (section 5-7-1) is set to YPbPr
SMPTE, YPbPr BETACAM, RGB, or Y/C
COMPOSITE
LOSS
525/60
625/50
BY-PASS
Displays the video format of the COMPOSITE input
signal.
Displays “LOSS” if there is no input signal.
REFERENCE
LOSS
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
PAL-M
*1
UNKNOWN
Displays the video format of the genlock input signal.
Displays “LOSS” if there is no input signal.
Displays “UNKNOWN” if there is an unsupported input
signal.
*1 Shown when Mode in the 5-12 PAL-M MODE SET is set to ENABLE, and an input signal in
GENLOCK IN connector is 525/60 or PAL-M signal.
Menu button
STATUS
OTHER
