11. ANALOG/DIGITAL Audio Input/Output Level
11-1. Analog Output Level Relative to the Digital Input Level
 Digital Reference Level: -18dBFS
ANALOG OUT LEVEL setting
Digital audio input level -10 dBm 0 dBm 4 dBm 8 dBm
-24 dBFS -16 dBm -6 dBm -2 dBm +2 dBm
-20 dBFS -12 dBm -2 dBm +2 dBm +6 dBm
-18 dBFS -10 dBm 0 dBm +4 dBm +8 dBm
0 dBFS +8 dBm +18 dBm +22 dBm CLIP
 Digital Reference Level: -20dBFS
ANALOG OUT LEVEL setting
Digital audio input level -10 dBm 0 dBm 4 dBm 8 dBm
-24 dBFS -14 dBm -4 dBm 0 dBm +4 dBm
-20 dBFS -10 dBm 0 dBm +4 dBm +8 dBm
-18 dBFS -8 dBm +2 dBm +6 dBm +10 dBm
0 dBFS +10 dBm +20 dBm +24 dBm CLIP
 Digital Reference Level: -24dBFS
ANALOG OUT LEVEL setting
Digital audio input level -10 dBm 0 dBm 4 dBm 8 dBm
-24 dBFS -10 dBm +0 dBm +4 dBm +8 dBm
-20 dBFS -6 dBm +4 dBm +8 dBm +12 dBm
-18 dBFS -4 dBm +6 dBm +10 dBm +14 dBm
0 dBFS +14 dBm +24 dBm CLIP CLIP

See REF LEVEL in section 6-10-2. "DIGITAL AUDIO" for details on the Digital
Reference Level setting.
See section 6-3-3. "ANALOG OUT LEVEL" for details on the ANALOG OUT
LEVEL setting.
