2-3. Internal Settings
IMPORTANT
Note that internal switch settings should not be changed from factory defaults. If you
have accidentally changed the settings, return them to the factory default settings as
shown in this section.
Be sure to have qualified technical personnel perform the settings and adjustments in
the interior, or contact your dealer.
CAUTION
Do not access any internal cards while the unit is powered ON. Always power OFF all
connected units / disconnect power cords prior to accessing the interior. To protect
boards from electrostatic damage, do not touch the components on the boards.
2-3-1. Dipswitch Settings
The following settings can be made at the dipswitches on MAIN CARD inside the unit.
Dipswitch S1 Settings
Pin No. Default setting Setting
1 ON Do not change.
2 OFF Do not change.
3 OFF Do not change.
4 OFF Do not change.
5 OFF Do not change.
6 OFF Do not change.
7 OFF Do not change.
8 OFF Do not change.
Dipswitch S2 Settings
Pin No. Default setting Setting
1 ON Do not change.
2 OFF Do not change.
3 OFF Do not change.
4 OFF Do not change.
5 OFF
If the FA-95DACBL is installed in SLOT A: OFF
If the FA-95DACBL is installed in SLOT B: ON
If the FA-95DACBL is not installed: OFF
6 OFF Do not change.
7 OFF
Standard FA-9500: OFF (without FA-95PS)
If the FA-95PS is installed: ON
8 OFF Do not change.
