239
14-4. GPI Output Circuit
IMPORT
ANT
Note that the allowed current
for each GPI output circuit is
10mA
and the external
power supply should be
5VDC
.
+5.4V
Select external or internal
power.
PIN 9
PINs 2-8
PIN 1
5VDC
(external power)
Protective resisto
r
FA-9500 inside
254
256
