5-13-9. AES IN AUDIO
AES IN AUDIO 543
CH 1:LOSS
CH 2:LOSS
CH 3:LOSS
CH 4:LOSS
AES IN AUDIO 544
CH 5:LOSS
CH 6:LOSS
CH 7:LOSS
CH 8:LOSS
Parameter Display Description
CH1 - CH8
LOSS
PCM 48kHz
PCM 44.1kHz
PCM 32kHz
PCM Other
SILENCE 48kHz
SILENCE 44.1kHz
SILENCE 32kHz
SILENCE Other
NON-PCM
OUTPUT SETTING
Displays the status of the audio signal input to the
DIGITAL AUDIO IO connectors.
LOSS: No audio signals
PCM 48kHz: Normal audio signal (approx. 48kHz)
PCM 44.1kHz: Normal audio signal (approx. 44.1kHz)
PCM 32kHz: Normal audio signal (approx. 32kHz)
PCM Other: Normal audio signal (Non AES input)
SILENCE 48kHz: Mute signal (approx. 48kHz)
SILENCE 44.1kHz: Mute signal (approx. 44.1kHz)
SILENCE 32kHz: Mute signal (approx. 32kHz)
SILENCE Other: Mute signal (Non AES input)
NON-PCM: Compressed audio data such as AC3
OUTPUT SETTING: Connector is set to output
5-13-10. ANALOG IN AUDIO
ANALOG IN AUDIO 545
CH 1:LOSS
CH 2:LOSS
CH 3:LOSS
CH 4:LOSS
Parameter Display Description
CH1 - CH4
LOSS
IN
Displays the status of the input audio signal in
the ANALOG AUDIO connector.
LOSS: No audio signal is present.
IN: An audio signal is present.
