121
6-10-2. DIGITAL AUDIO
DIGITAL AUDIO 182
REF LEVEL :-20dBFS
GRADE:PROFESSIONAL
RESOLUTION:24bit
Parameter Default Setting range Description
REF LEVEL -20dBFS
-18dBFS
-20dBFS
-24dBFS
Selects the reference level for
digital audio signals.
See section 11
“ANALOG/DIGITAL Audio
Input/Output Level” for details.
GRADE PROFESSIONAL
PROFESSIONAL
CONSUMER
Selects an audio application for
AES and SDI AUDIO outputs.
PROFESSIONAL: Optimized for
professional use.
CONSUMER: Optimized for
consumer use.
RESOLUTION 24bit
24bit,
20bit,
16bit
Selects an audio word length for
AES and SDI AUDIO outputs.
6-10-3. AUDIO ERR SENSE
AUDIO ERR SENSE 183
CH SEL :SDI 1/2
CH STATUS:SRC BYPASS
VALIDITY :SRC BYPASS
Parameter Default Setting range Description
CH SEL SDI 1/2
SDI 1/2 - SDI 15/16
AES 1/2 - AES 7/8
Selects a stereo channel pair for which to
enable Audio Error SENSE.
CH STATUS
SRC
BYPASS
SRC BYPASS
PCM
MUTE
Selects audio error sensor mode for each
stereo channel pair of SDI and AES input
audio signals whose NON-PCM channel
status flag is 1.
*1
SRC BYPASS: Treats audio signals as
NON-PCM. By-passes audio signals
through SRC
*2
, and selects audio clock
input in the NON-PCM signal channel for
SDI AUDIO CLOCK.
*3
PCM: Treats audio signals as PCM
(standard audio signal). By-passes audio
signals through SRC
*2
, and selects
REFERENCE for SDI AUDIO CLOCK.
*3
MUTE: Treats audio signals as mute
signals.
VALIDITY
SRC
BYPASS
SRC BYPASS
PCM
MUTE
Selects audio error sensor mode for each
stereo channel pair of SDI and AES input
audio signals whose channel status
Validity Bit flag is 1.
*1
SRC BYPASS: Treats audio signals as
NON-PCM. By-passes audio signals
through SRC
*2
, and selects audio clock
input in the NON-PCM signal channel for
SDI AUDIO CLOCK.
*3
PCM: Treats audio signals as PCM
(standard audio signal). By-passes audio
signals through SRC
*2
, and selects
REFERENCE for SDI AUDIO CLOCK.
*3
MUTE: Treats audio signals as mute
signals.
Menu button
VIDEO SYS
AUDIO SYS
Menu button
VIDEO SYS
AUDIO SYS
