5-13-14. ANALOG OUT AUDIO
ANALOG OUT AUDIO 571
CH 1:SILENCE
CH 2:SILENCE
CH 3:SILENCE
CH 4:SILENCE
Parameter Display Description
CH1 - CH4
SILENCE
OUT
Displays the status of the output audio signal
from the ANALOG AUDIO connector.
SILENCE: Mute signal
OUT: Output signal is present
5-13-15. Dolby AUX STATUS
* This menu is available only if FA-95D-D option is installed.
DolBy AUX STATUS 573
INPUT :LOSS
OUTPUT:NONE
REFERENCE:LOSS
Parameter Display Description
INPUT
LOSS
PCM
NON-PCM
UNKNOWN
Displays status or type of signal input to the
optional Dolby input connector (Dolby IN).
LOSS: No audio signal
PCM: Standard audio signal
NON-PCM: Compressed audio data such as
Dolby E encoded data
UNKNOWN: Unknown signal.
OUTPUT
PCM
NON-PCM
NONE
Displays status or type of signal output to the
optional Dolby output connectors (Dolby OUT).
PCM: Standard audio signal
NON-PCM: Compressed audio data such as
Dolby E encoded data
NONE: No signal
REFERENCE
LOSS
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
UNKNOWN
Displays signal format of reference signal input
to the optional Dolby REF IN connector.
LOSS: No signal
UNKNOWN: Unknown signal format
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
