5-13-11. SDI 1/2 OUT AUDIO
SDI1/2 OUT AUDIO 561
CH 1:PCM
CH 2:PCM
CH 3:PCM
CH 4:PCM
SDI1/2 OUT AUDIO 562
CH 5:PCM
CH 6:PCM
CH 7:PCM
CH 8:PCM
SDI1/2 OUT AUDIO 563
CH 9:PCM
CH10:PCM
CH11:PCM
CH12:PCM
SDI1/2 OUT AUDIO 564
CH13:PCM
CH14:PCM
CH15:PCM
CH16:PCM
Parameter Display Description
CH1 - CH16
PCM
SILENCE
NON-PCM
UNKNOWN
BLANK
BY-PASS
Displays the status of audio signal channels CH1
through CH16 of the SDI 1/2 output.
PCM: Normal audio signal
SILENCE: Mute signal
NON-PCM: Compressed audio data such as AC3
UNKNOWN: Unidentifiable
BLANK: No audio signal embedding
BY-PASS: By-passed through
Menu button
STATUS
OTHER
