19. FA-9500 Ancillary Data Packet Name List
FA-9500 Indication
DID/SDID
(hexadecimal)
Description
S353MMPEG(V) 08/08 MPEG recoding data, VANC space (Picture rate information)
S353M MPEG(H) 08/0C MPEG recoding data, HANC space (Other part of recording data set)
S305M SD-SDTI 40/01 ARIB STD-B17 Serial Data Transport Interface for Television
S305M HD-SDTI 40/02 ITU-R BT.1557, SMPTE 348M for HD-SDTI
S427 Lk Enc 1 40/04 SMPTE 427 Link Encryption Message 1
S427 Lk Enc 2 40/05 SMPTE 427 Link Encryption Message 2
S427 Lk Meta 40/06 SMPTE 427 Link Encryption Metadata
S352M VPID 41/01 BTA S-004C Video Payload Identification for Digital Interfaces
S2016-3 AFD-Bar 41/05 SMPTE 2016-3 AFD and Bar Data
S2016-4 PanScan 41/06 SMPTE 2016-3 Pan-Scan Data
RP2010 SCTE 104 41/07 SMPTE 2010 ANSI/SCTE 104 messages
S2031 SCTE VBI 41/08 SMPTE 2010 DVB/SCTE VBI data
ITU-R BT.1685 43/01 ITU-R BT.1685 Inter-station control data packets
RDD8 OP47(SDP) 43/02 SMPTE RDD 8 Subtitling Distribution packet(SDP)
RDD8 OP47(Mult) 43/03 SMPTE RDD 8 Transport of ANC packet in an ANC Multipacket
S346M 43/13 Time Division Multiplexing Video Signals and Generic Data over HD-SDI
RP214 KLV(V) 44/04 SMPTE RP 214 KLV Metadata transport in VANC space
RP214 KLV(H) 44/14 SMPTE RP 214 KLV Metadata transport in HANC space
RP223 UMID 44/44 SMPTE RP 223 Packing UMID and Program Identification Label
Data into SMPTE 291M Ancillary Data Packets
S2020 Aud 45/01 SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr1/2 45/02 SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr3/4 45/03 SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr5/6 45/04 SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr7/8 45/05 SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr9/10 45/06 SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr11/12 45/07 SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr13/14 45/08 SMPTE 2020-1 Compressed Audio Metadata
S2020 AudP15/16 45/09 SMPTE 2020-1 Compressed Audio Metadata
RP215 Film Xfer 51/01 RP215 Film Codes in VANC space
ARIB TRB.18 5F/CF Color information packets standarized in ARIB TR-B18 “Color Frame
Information for Component Interface of 525/60 Television System”
ARIB B.37 1D0
・
・
2DB
Closed caption data packets (for expansion) standarized in ARIB STD-B37
“Structure and Operation of Closed Caption Data Conveyed by Ancillary
Data Packets”
ARIB B.37 Mob 5F/DC Caption format used in digital television broadcasting for mobile receivers
standarized in ARIB STD-B37“Structure and Operation of Closed Caption
Data Conveyed by Ancillary Data Packets”
ARIB B.37 Ana 5F/DD Analog signal closed caption data packets standarized in ARIB STD-B37
“Structure and Operation of Closed Caption Data Conveyed by Ancillary
Data Packets”
ARIB B.37 SD 5F/DE SD signal closed caption data packets standarized in ARIB STD-B37
“Structure and Operation of Closed Caption Data Conveyed by Ancillary
Data Packets”
ARIB B.37 HD 5F/DF HD signal closed caption data packets standarized in ARIB STD-B37
“Structure and Operation of Closed Caption Data Conveyed by Ancillary
Data Packets”
ARIB TR-B.22 5F/E0 HD ancillary data packet for transmission standarized in ARIB TR-B22
“Operational Guidelines for Transport of the Ancillary Data for HDTV
Contribution”
ARIB TRB23(1) 5F/FA Dummy packet standarized in ARIB TR-B23 ” Operational Guidelines for
Ancillary Data in Inter-Stationary Information Exchange”
ARIB TRB23(2) 5F/FB User data 2 in user data packets standarized in ARIB TR-B23 “ Operational
Guidelines for Ancillary Data in Inter-Stationary Information Exchange”
