246
Object group
Menu name in
FA-9500
Item name in FA-9500 Description Object name in MIB file OID Type Write Read Trap
Trap event
(value)
OID: 1.3.6.1.4.1.20175.1.301.2.4.1（FS MODE)
VIDEO
SYSTEM
FS Mode
SYNCHRO MODE
0: FRAME
1: LINE
2: INPUT
3：AVDL
fa95VideoSyncMode 1 INTEGER ○ ○ - -
Sync Format
0: Auto
1: 525/60
2:625/50
3: 1080/59.94i
4:1080/50i
5: 720/59.94p
6:720/50p
7:1080/23PsF
8:1080/24PsF
19:1080/59p
20:1080/50p
fa95VideoSystemFormat
2 INTEGER ○ ○ - -
OID: 1.3.6.1.4.1.20175.1.301.2.4.2.（FREEZE)
FREEZE
FREEZE
SETTING
FREEZE On/Off
Freeze On/Of
f
0: Off
1: On
fa95FreezeEnable 1 INTEGER ○ ○ - -
FREEZE Mode
0: Frame
1: Odd
2: Even
fa95FreezeMode 2 INTEGER ○ ○ - -
OID: 1.3.6.1.4.1.20175.1.301.2.4.3. (Composite setting)
COMPOSITE
Composite
Setting
3D COMB
0: Adaptive 3D
1: Adaptive 2D
2: Trap Onl
y
fa95VbsCombFilter 1 INTEGER ○ ○ - -
NR Level 0-4: Off Level1-4 fa95VbsNRFilte
r
2 INTEGE
R
○ ○ - -
Cross Colo
r
0-3: Off Level1-3 fa95VbsCrossColorFilte
r
3 INTEGE
R
○ ○ - -
OID: 1.3.6.1.4.1.20175.1.301.2.6（Converter 1)
Converter 1
CONV1 U/D
MODE
Convert Mode *1
0: BY-PASS
1: Aspect
2: SD
3: 1080i
4: 720p
6: 1080PsF
7: 1080p
(
3G
)
fa95Conv1Mode 1
INTEGER ○ ○ - -
Aspect
0: 4: 3
1: 13: 9
2: 14: 9
3: 16: 9
4: Squeeze
fa95Conv1Aspect 2 INTEGER ○ ○ - -
Aspect(SD)
0: AFD(4:3)
1: AFD-ALT(4:3)
2: AFD(16:9)
3: AFD(16:9)
4: Letterbox 16:9 top
5: Letterbox 14:9 top
6: Letterbox>16:9(4:3)
7: Fullframe 4:3
8: Letterbox 16:9
9: Letterbox 14:9
10: Fullframe 4:3 Alt 14:9
11: Letterbox 16:9 Alt 14:9
12: Letterbox 16:9 Alt 4:3
13: Letterbox>16:9(16:9)
14: Fullframe 16:9
15: Pillarbox 4:3
16: Fullframe 16:9 Protected
17: Pillarbox 14:9
18: Pillarbox 4:3 Alt 14:9
19: Fullframe 16:9 Alt 14:9
20: Fullframe 16:9 alt 4:3
fa95Conv1AspectSD 4 INTEGER ○ ○ - -
Aspect(HD)
0: AFD
1: AFD-ALT
2: Letterbox>16:9
3: Fullframe 16:9
4: Pillarbox 4:3
5: Fullframe 16:9 Protected
6: Pillarbox 14:9
7: Pillarbox 4:3 Alt 4:9
8: Fullframe 16:9 Alt 14:9
9: Fullframe 16:9 alt 4:3
fa95Conv1AspectHD 5 INTEGER ○ ○ - -
CONV1
IMPROVE
Motion Sense
1: Field
2: Frame(Odd 1
st
)
3: Frame(Even 1
st
)
4: Adaptive
fa95Conv1MotionSense 31
INTEGER ○ ○ - -
Enhance 0～8 fa95Conv1Enhance 42 INTEGE
R
○ ○ - -
A
ntialias H -8～0～+8 fa95Conv1AntiAlias 43 INTEGE
R
○ ○ - -
A
ntialias
V
-8～0～+8 fa95Conv1AntiAlias 44 INTEGE
R
○ ○ - -
OID: 1.3.6.1.4.1.20175.1.301.2.7（Converter 2)
Converter 2
CONV2 U/D
MODE
Convert Mode *1
0: BY-PASS
1: Aspect
2: SD
3: 1080i/SD
4: 720p/SD
6: 1080PsF/SD
7: 1080p
(
3G
)
/SD
fa95Conv2Mode 1 INTEGER ○ ○ - -
Aspect(SD)
0: AFD(4:3)
1: AFD-ALT(4:3)
2: AFD(16:9)
3: AFD(16:9)
4: Letterbox 16:9 top
5: Letterbox 14:9 top
6: Letterbox>16:9(4:3)
7: Fullframe 4:3
8: Letterbox 16:9
9: Letterbox 14:9
10: Fullframe 4:3 Alt 14:9
11: Letterbox 16:9 Alt 14:9
12: Letterbox 16:9 Alt 4:3
13: Letterbox>16:9(16:9)
14: Fullframe 16:9
15: Pillarbox 4:3
16: Fullframe 16:9 Protected
17: Pillarbox 14:9
18: Pillarbox 4:3 Alt 14:9
19: Fullframe 16:9 Alt 14:9
20: Fullframe 16:9 alt 4:3
fa95Conv2AspectSD 4 INTEGER ○ ○ - -
*1 Specifies/displays the operation for when VideoOutMOde is set to Fix.
