163
 Composite Output Setting
Allows you to assign video signals to output from the Composite output connectors.
Parameter Default
Setting range
(Steps)
Description
Assign Converter1
Converter1
Converter2
Selects whether to output a
Converter1 or 2 signal from
COMPOSITE OUT connectors.
The input and output signal formats are displayed; e.g., 625/50>> 1080/50i.
 Component Output Setting
This menu appears only if the FA-95AIO option is installed.
Allows you to assign video signals to video output pins to output to the FA-95AIO Component
I/O connector.
Parameter Default
Setting range
(Steps)
Description
Assign Converter1
Converter1
Converter2
Selects whether to output a Converter1 or 2
signal from the ANALOG COMPONENT I/O
connector.
Displays formats of input signals to the converter and converted output signal from the
converter as 625/50>> 1080/50i.
Output Mode
Parameter Default
Setting range
(Steps)
Description
Output Mode
YPbPr
SMPTE
YPbPr SMPTE
YPbPr BETACAM
RGB
Y/C
Selects an output mode for ANALOG
COMPONENT(FA-95AIO) signals.
SMPTE and BETACAM are SD-SDI
output formats.
* Outputs black signals if the output signal/s from CONV1 and CONV2 is/are 1080p, and
FA-95AIO output is set to YPbPr or RGB. See the YPbPr/RGB Output Format table in
section 5-8-4 “COMPONENT SET”.
* Outputs black signals if the output signal/s from CONV1 and CONV2 is/are HD-SDI, and
FA-95AIO output is set to Y/C. See the YPbPr/RGB Output Format table in section 5-8-4
“COMPONENT SET”.
