190
*2 SOURCE channels corresponding to CH1-8 will be the default value.
If Input Selection is set to Direct Input Selection, the settings will be; CH1: Source CH1 -
CH8: Source CH8.
If Input Selection is set to Dolby Decoder Output, the settings will be; CH1: Dolby DEC 1 -
CH8: Dolby DEC 8.
Dolby Encoder Mode Setting
Parameter Default Setting range Description
Program
Configuration
5.1+2
5.1+2
*1
5.1+2x1
*1
4+4
*1
4+2x2
*1
4+2+2x1
*1
4+4x1
*1
4x2
*1
3x2+2x1
*1
2x2+4x1
*1
2+6x1
*1
8x1
*
1
5.1
4+2
4+2x1
3x2
2x2+2x1
2+4x1
6x1
4
2+2
2+2x1
4x1
7.1
*1
7.1 Screen
*1
Selects Dolby E encoder program
configuration.
*1
Bit Depth 20bit
20bit
16bit
Selects the bit width of the Dolby E
encoder output.
Frame REF CONV1
CONV1
CONV2
Selects a video output to which the
Dolby E encoder output is
synchronized. (Converter 1 or
converter 2)
*2
Meta Data
Input
Internal
Internal
Dolby Decoder Output
Selects a metadata to be used for
Dolby E encoding.
Internal: Uses Program
Configuration and Bit Depth settings.
Other metadata will be reset to
default.
Dolby Decoder Output: Uses the
metadata of the Dolby E signal input
to the Dolby decoder. The program
configuration and bit depth settings
will be ineffective.
*1 If Bit Depth is set to 16bit, the “＊“ is displayed and the program functions as 5.1. To set to
the above program configurations, set Bit Depth to 20bit.
*2 See section 9-2-6 Converter1 for details on CONV1 and CONV2 settings.
