203
 ANC Data Embed
Parameter Default Setting range Description
ANC CEA608 CC
CEA608 CC
S334-1 CC SD
CEA708 CC HD
S2016-3 AFD
RP186 VI
BT1119 WSS
Selects an ancillary data type to be
inserted into SDI signals.
Format *
Selects a video format compatible with
the ancillary data selected under ANC.
Only compatible Video formats will be
displayed.
Embed Disable
Disable
Converter1
Converter 2
Converter 1/2
Disable: Does not insert the ancillary
data selected under ANC.
Converter1: Inserts ancillary data
selected under ANC into the Converter
1 output signal.
Converter2: Inserts ancillary data
selected under ANC into the Converter
2 output signal.
Converter1/2: Inserts ancillary data
selected under ANC into Converter 1
and Converter 2 output signals.
This value can be set for each ANC
selection (S334-1 CC SD to BT1119
WSS) under ANC respectively.
Line
Field 1
- *
Selects a line in an ancillary data space
into which to insert the ancillary data. A
line can be selected for different ANC
and FORMAT selections separately.
If ANC is set to RP186 VI, this
parameter allows you to select a line
for Field 1 while a line for respective
fields can be selected.
Field 2 *
If ANC is set to RP186 VI, this
parameter allows you to select a line
for Field 2 while a line for respective
fields can be selected.
* The setting range varies by ancillary data type and video format.
Ancillary data type FORMAT LINE Default
ANC:CEA 608 CC 525/60 21(284) Line fixed
*1
ANC:S334-1 CC SD 525/60 12(275) to 19(282) Line
*1
12(275) Line
*1
ANC:CEA708 CC HD
1080i 9 to 20 Line 9 Line
720p 9 to 25 Line 9 Line
ANC:S2016-3 AFD
525/60 12(275) to 19(282) Line
*1
12(275) Line
*1
625/50 8(321) to 22(335) Line
*1
8(321) Line
*1
1080i/PsF 9 to 20 Line 9 Line
720p 9 to 25 Line 9 Line
1080p/(3G) 9 to 41 Line 9 Line
ANC:RP186 VI
525/60
Field 1 12 to 19 Line 14 Line
Field 2 275 to 282 Line 277 Line
625/50
Field 1 8 to 22 Line 11 Line
Field 2 321 to 335 Line 324 Line
ANC:BT1119 WSS 625/50 Fiels 1 8 to 23 Line 23 Line
*1 Field2 line number will be displayed in the parenthesis.
