FOR-A FA-9500 - 9-7-3. Unit Information

205
 ANC Loss Mode Settings
Parameter Default Setting range Description
ANC S2016-3 AFD
S2016-3 AFD
RP186 VI
BT1119 WSS
Selects an ancillary data type to insert
into the SDI signal.
Format SD
SD
HD
*1
Selects a video format compatible with
the ancillary data selected under ANC.
Only compatible Video formats will be
displayed
Mode Remove
If Format is set to SD
Remove
Hold
4:3 L 16:9 T
*2
4:3 L14:9 T
*2
4:3 L>16:9
*2
4:3 F 4:3
*2
4:3 L16:9PRTD
*2
4:3 L 14:9
*2
4:3 F ALT14:9
*2
4:3 L ALT14:9
4:3 L ALT 4:3
16:9 L>16:9
16:9 F FRM
*2
16:9 P 4:3
16:9 F PRTD
16:9 P 14:9
16:9P ALT14:9
16:9F ALT14:9
16:9 F ALT4:3
MODE can be set for respective ANC
and FORMAT selections.
Remove: Does not embed the
ancillary data to either CONV1, or 2.
Hold: Retains the last ancillary data
aspect ratio and outputs video signal
in the aspect ratio.
Other values operate according to the
selected AFD as an input AFD.
BT1119 WSS selected under ANC
can only select AFD codes indicated
by
*2
.
If Format is set to HD
Remove
Hold
16:9 L>16:9
16:9 F 16:9
16:9 P 4:3
16:9 F PRTD
16:9 P 14:9
16:9 P ALT14:9
16:9 F ALT14:9
16:9 F ALT4:3
*1 HD is selectable only when ANC is set to S2016-3.
 WSS AFD Error
Parameter Default Setting range Description
Mode Remove
Remove
F 4:3
Remove:
Does not embed BT1119 WSS to
CONV1 and/or 2.
F 4:3:
Embeds BT1119 WSS F 4:3 (code 8)
to CONV1 and/or 2.
