Parameter Default Setting range(Steps) Description
Assign
*2
None
In case Input/Output is set to
Output
None
*3
Freeze
*3
Video In
*3
Audio In
*3
REF In
*3
FAN Alarm
*3
DC Power1
*3 *8
DC Power2
*3 *8
Selected SDI1
*3
Selected SDI2
*3
Selected Composite
*3
Selected YPbPr SMPTE
*9
Selected YPbPr BETACAM
*9
Selected RGB
*9
Selected Y/C
*9
Changeover
*5
Changeover Enable
*5
CONV1 Keyer
CONV2 Keyer
Assigns a function to GPI pins 1
through 7 according to the selection
under In/Out.
Logo ID
*10
1-7 1-256
Sets ID (1 through 256) to logos to be
inserted for outputs 1 through 7 of
converters 1 and 2.
*1 Whenever the In/Out setting is changed, Assign is reset to None. Reset Assign.
*2 The input functions consist of pulse mode and level mode functions. See the “◆INPUT
FUNCTION” in section 7-3 “GPI SETTING” for details.
*3 Details of the output functions are shown in the “◆OUTPUT FUNCTION” in section 7-3 “GPI
SETTING”.
*4 Input assignment cannot be changed if FA-95CO is installed with Changeover enabled. To
enable input assignments, set Input Select (section 9-2-1) to disable.
*5 Changeover is selectable only if FA-95CO is installed.
*6 If FS Mode > Synchro Mode in section 9-4-1 “Video System” is set to Line Sync, AVDL, or
Input Lock, the Freeze setting will not function, but will be displayed as *Freeze.
To enable Freeze for Input, be sure to set Synchro Mode in section 9-4-1 “Video System” to
Frame Sync.
*7 When the FA-95CO is installed and Changeover is enabled the value will be displayed with an
asterisk as *Input SDI1, *Input SDI2, or *Input Composite indicating the input selection
cannot be changed. See section 9-2-1 “Input Select” for details.
*8 DC Power 1 and 2 are selectable only if FA-95PS is installed.
*9 Selectable only if FA-95AIO is installed.
*10 The Logo ID setting box will be displayed when In/Out is set to Input, and Assign is set to any
of CONV1 Load 1 – 7 or CONV2 Load 1 – 7. In the following cases, the logo will not be
inserted to the converter output signals, although data will be loaded to the FA-9500.
- No logo is registered under the selected Logo ID.
- The registered logo format and converter output video format do not match.
- The keyer of the relevant converter is turned off.
