FOR-A FA-9500 - 16. FA-95 AIO Option; 16-1. FA-95 AIO Pin Assignments

226
 Changeover Video Status
Displays the status of video-related triggers at the time a changeover is performed.
Item Description
SDI Error
Disable: This trigger is disabled.
Non-Trigger: This trigger is enabled, but has not triggered a changeover.
Trigger: This trigger is enabled, and has triggered a changeover.
Format Error
Disable: This trigger is disabled.
Non-Trigger: This trigger is enabled, but has not triggered a changeover.
Trigger: This trigger is enabled, and has triggered a changeover.
CRC Error
Disable: This trigger is disabled.
Non-Trigger: This trigger is enabled, but has not triggered a changeover.
Trigger: This trigger is enabled, and has triggered a changeover.
Black Video
Disable: This trigger is disabled.
Non-Trigger: This trigger is enabled, but has not triggered a changeover.
Trigger: This trigger is enabled, and has triggered a changeover.
 Changeover Audio Status
Displays the status of audio-related triggers at the time a changeover is performed.
Item Description
Audio Loss
Disable: This trigger is disabled.
Non-Trigger: This trigger is enabled, but has not triggered a changeover.
Trigger: This trigger is enabled, and has triggered a changeover.
Audio Error
Disable: This trigger is disabled.
Non-Trigger: This trigger is enabled, but has not triggered a changeover.
Trigger: This trigger is enabled, and has triggered a changeover.
Silence
Disable: This trigger is disabled.
Non-Trigger: This trigger is enabled, but has not triggered a changeover.
Trigger: This trigger is enabled, and has triggered a changeover.
 Audio Loss Status
Displays status details of audio-related triggers at the time a changeover is performed.
Item Description
Group 1 to 4
Disable: This trigger is disabled for audio groups 1 to 4 respectively.
Non-Trigger: This trigger is enabled, but has not triggered a changeover
for audio groups 1 to 4 respectively.
Trigger: This trigger is enabled, and has triggered a changeover for audio
groups 1 to 4 respectively.
 Audio Error Status
Displays Audio Error trigger status details at the time a changeover is performed.
Item Description
CH1 1 to 16
Disable: Audio Error trigger is disabled for audio channels 1 to 16
respectively.
Non-Trigger: Audio Error trigger is enabled, but has not triggered a
changeover for audio channels 1 to 16 respectively.
Trigger: Audio Error trigger is enabled, and has triggered a changeover for
audio channels 1 to 16 respectively.
 Silence Status
Displays Silence trigger status details at the time a changeover is performed.
Item Description
CH1 1 to 16
Disable: Silence trigger is disabled for audio channels 1 to 16
respectively.
Non-Trigger: Silence trigger is enabled, but has not triggered a
changeover for audio channels 1 to 16 respectively.
Trigger: Silence trigger is enabled, and has triggered a changeover for
channels 1 to 16 respectively.
