The figures below compare the reference values (dotted line) for output and the actual values
after correction (full line).
Relationship between IN BLACK, IN WHITE and TARGET BLACK, TARGET WHITE levels
Large TARGET BLACK setting
0% 100%
TARGET BLACK
Small TARGET BLACK setting
0% 100%
TARGET BLACK
Small TARGET WHITE setting
0% 100%
TARGET WHITE
Large TARGET WHITE setting
0% 100%
TARGET WHITE
0% 100%
0% 100%
IN WHITE IN BLACK
TARGET BLACK TARGET WHIE
Input image
Output image
