109
Recording Video and Key Signals Simultaneously
Assume a video signal is assigned to AUX3 and its key signal to AUX4.
If you need to record an input signal such as IN01, assign the signal to an AUX bus before
recording.
Let's record AUX3 video and AUX4 key signals simultaneously to clips through STILL 2.
(1) Open the [STILL] menu PAGE 1.
(2) Turn F2 to select CLIP under STILL2.
(3) Select AUX3 and AUX4 for FILL SOURCE and KEY SOURCE, respectively.
STILL :STILL1 :STILL2 :FIL SRC:KEY SRC: 1/5
STORE : >FRAME: >CLIP : =AUX3 : =AUX4 :
(4) Go to PAGE 4.
(5) Turn F1 to select STL2.
(6) Press F4 while holding down F3 to begin recording.
STILL :SELECT : ( STOP ---/0 ): 4/5
CLIP : =STL2 : >STOP : >REC : >PLAY : F=0
(7) Press F2 (STOP) or F4 (PAUSE) to stop recording.
Loop Recording
Loop recording automatically loops back to the memory start point when it reaches the
end of the memory and continues recording overwriting clip frames, until STOP is pressed.
If LOOP is set to ON, both playback and recording change to Loop mode.
LOOP can be set to ON on PAGE 5 of the [STILL] menu as shown below.
STILL :SELECT : LOOP :REC MOD:CLEAR : 5/5
CLIP : =STL2 : =ON : =STD : >OFF : F=40
Recording Mode
Two modes are available for recording. The recording mode can be set under REC MODE
on PAGE 5 of the [STILL] menu.
STILL :SELECT : LOOP :REC MOD:CLEAR : 5/5
CLIP : =STL2 : =OFF : =STD : >OFF : F=40
Standard mode.
In this mode, to start recording, press F4 (PLAY) while holding
down F3 (REC) on PAGE 4.
Direct mode.
In this mode, to begin recording, press F3 (REC) on PAGE 4.
