 TALLY function

FUNCTION setting

Description

KEY1 ON TLY

KEY2 ON TLY

DSK1 ON TLY

DSK2 ON TLY

Outputs tally signal when KEY or DSK is on the

background video.

FAN ERROR ALARM

Outputs power or fan alarm.

XT100

PS1-2 ERROR ALARM

ALL ALARM

RED TALLY-BLACK

Outputs a red tally when the specified signal is sent to the

red (tally color) bus.

XT100

RED TALLY-IN01-08

XT110

RED TALLY-IN01-12

RED TALLY-STIL1-2

RED TALLY-STILK1-2

RED TALLY-MATT1-2

RED TALLY-CKFIL

RED TALLY-CKKEY

RED TALLY-EFF1-2

RED TALLY-PGM

RED TALLY-PREV

RED TALLY-CLN

GREEN TALLY-BLACK

Outputs a green tally when the specified signal is sent to

the green (tally color) bus.

XT100

GREEN TALLY-IN01-08

XT110

GREEN TALLY-IN01-12

GREEN TALLY-STIL1-2

GREEN TALLY-STILK1-2

GREEN TALLY-MATT1-2

GREEN TALLY-CKFIL

GREEN TALLY-CKKEY

GREEN TALLY-EFF1-2

GREEN TALLY-PGM

GREEN TALLY-PREV

GREEN TALLY-CLN

AUX1 to 8 TRANS ENABLE

Outputs tally signal when AUX transition is enabled.
