FOR-A HVS-XT100 User Manual

86
 Signal Mask
Video inputs can be used for mask signals instead of Box. Inputs used for masks must be
assigned to AUX1 to AUX8. Combined video signals such as program or multi-view cannot
be used.
(1) Open [KEY1 - MASK] menu PAGE 1. (See the previous page.)
(2) Turn F3 to select a mask signal.
(3) If you want to invert a key signal, turn F4 to ON.
(4) Set TYPE to AND or OR.
KEY1 : TYPE :BOX MSK:MASK(EXT/PST) : 1/5
MASK : =AND : =OFF : S=AUX5:INV=ON :
 Preset Mask
WIPE patterns can be used for mask signals for KEY1 and KEY2.
(1) Open the [KEY1 - MASK] menu PAGE 1. (See the previous page.)
(2) Turn F3 to select PST (PRESET).
(3) If you want to invert a key signal, turn F4 to ON.
(4) Set TYPE to AND or OR.
KEY1 : TYPE :BOX MSK:MASK(EXT/PST) : 1/5
MASK : =AND : =OFF : S=PST :INV=ON :
(5) Press PAGE DOWN to go to PAGE 3.
(6) Turn F1 to select a wipe pattern.
(7) Turn F4 to change the pattern shape.
KEY1 :PATTERN : :LEVEL : 3/5
WIP PTRN: =51 : : =50.0 :
(8) Mask patterns can be modified referring to PAGE 4 and 5
KEY1 : POSITION : ANGLE :ASPECT : 4/5
WIP POS :X=0 Y=0 : =0.0 : =0.0 :
KEY1 : MULTI : SOFT : : 5/5
WIP MULT:X=1 Y=1 : =0.0 : :
