 Setting Example
(1) Set the key position and size on PAGE 1 of the [KEY1 - POS/SIZE] menu. Note that the
position is two-dimensional and its origin is placed on (0, 0), which coincides with the
center of the screen. The position values represent the distance between the origin and
the center of the KEY1 images. These values will be positive if the center of the key image
is above the origin and negative if it is below the origin.
KEY1 : POSITION : SIZE :2D DVE : 1/5
POS/SIZE:X=-200 Y=-200 : =500 : =ON :
To enter a negative number, enter the number, press ± , then press ENTER.
(2)Change the center of rotation on PAGE4 of the [KEY1 - POS/SIZE] menu. To rotate the
key image at the current POSITION, leave CENTER POSITION (0, 0, 0) unchanged.
KEY1 : CENTER POSITION : : 4/5
ROTATION:X=150 Y=-200 Z=-400 : :
(3) Set the rotation value on PAGE3 of the [KEY1 - POS/SIZE] menu.
KEY1 : LOCAL ROTATION : : 3/5
ROTATION:X=100 Y=100 Z=100 : :
[Example 1] X-axis Rotation
POSITION(-200,-200)
SIZE 500
Point of view
Screen surface
POSITION(-200,-200)
SIZE 500
CENTER POSITION (150,-200,-400)
Center of rotation
Point of view
Screen surface
POSITION (-200,-200)
SIZE 500
CENTER POSITION (150,-200,-400)
ROTATION (100,0,0)
Point of view
Screen surface
Center of
rotation
