Figure 64
Seang Adapter
Step 4
Review the posion of the power terminal adapter on the blade, verifying that no gap exists between the power
terminal adapter and the blade and that the power terminal adapter is slightly below the top of the blade.
Figure 65
Correcng Power Terminal Adapter Placement
Step 5
On a at ESD-safe surface, alternately ghten the aachment screws to secure the power terminal adapter onto
the blade, careful not to overghten them or ghten one screw completely before the other screw.
Cauon
: When ghtening the two screws, alternate between them; do not overghten either screw or
ghten one completely before ghtening the other.
Equipment Installation
Install Power Terminal Adapter
