Chapter 10 - Electrical Connections Page 263
Chapter 10 - Electrical Connections
For electrical diagrams for the CT components, refer to one of the following appropriate manuals:
• LightSpeed 2.X Schematics Manual, Direction 2243317-100 (for 4-slice SDAS Systems)
• LightSpeed 3.X Schematics Manual, Direction 2296441-100 (for 4 or 8-slice MDAS
Systems)
• LightSpeed 4.X Schematics Manual, Direction 2341962-100 (for 16-slice MDAS Systems)
10.1 Power and Data Cables Checklist
The following sections contain tables that list all the cables connecting the Discovery LS
subsystems.
10.1.1 CT Electronics Cabinet
The cables that connect to the CT Electronics cabinet are Red Coded.
Table 10-1: CT Electronics Cabinet Cables
Note 1: See the appropriate manual below:
• LightSpeed 2.X Installation Manual, Direction 2243312-100 (for 4-slice SDAS Systems)
• LightSpeed 3.X Installation Manual, Direction 2296439-100 (for 4 or 8-slice MDAS Systems)
• LightSpeed 4.X Installation Manual, Direction 2341957-100 (for 16-slice MDAS Systems)
Note 2: See Discovery LS Site Preparation Manual, Direction 2317947-100, Section 6.3.7.
Cable Connector Part Number Destination Notes
120 VAC
Power
J4 226880 Gantry 1/2 Turn
Plug
Control J2 2266014 Gantry
HVDC Power A2-TS1 2267642 (CPDU)
2347513 (NGPDU)
Gantry
HVAC Power A3-TB1 2267644 (CPDU)
2347514 (NGPDU)
Gantry Axial Motor
Power
Console
Power
J5 2266879 (CPDU)
2347378 (NGPDU)
Console
Interlock A4 Panel
See Note 1.
Room Door
X-ray Lamp A4 Panel Lamp
Main Power
Input
Input Power
Panel
See Note 2. Hospital
0utlet
Includes
Ground
Ground #1 A4 Panel
System
Ground
2275844 Ground Bar
on Table
Base
