DIRECTION 2307224-100, REVISION 6DISCOVERY LS SYSTEM SERVICE MANUAL
Chapter 6 - Table Page 189
6.2.7 Install Table Secondary Base Covers
Follow the procedure in this section to attach the covers to the Secondary Base of the
Automated Table. All Secondary Base cover hardware currently ships in a large plastic bag.
For best results, sort and inventory the hardware before you start to attach the brackets to
the table base.
6.2.7.1 Automated Table Cover Components
Refer to Figure 6-111. The upgrade kit contains the following secondary base covers:
Figure 6-111: Automated Table Covers
No. Description of Table Cover Section Part Number
A Back Cap 2320164
B Top Cap Short 2320161
C Left Side Cover 2320163
D Right Side Cover 2320162
E Table Top Cover 2333078
F Front Left Cover 2320166
G Front Right Cover 2320165
H Roller Cover 2331848
I Drip Trough 2333438
