GE Discovery LS - Automated and Extended Table Retractor Cables

GE HEALTHCARE
DIRECTION 2307224-100, REVISION 6DISCOVERY LS SYSTEM SERVICE MANUAL
Chapter 10 - Electrical Connections Page 267
10.1.4.2 Automated and Extended Table Retractor Cables
Table 10-5: Discovery LS Dynamic Table Cables (Automated & Extended Tables)
Cable Connector Part Number Destination
Table I/F J1 EXT Table Bulkhead
J1
2295952 CT Gantry
(Cable 2265881-2)
Table I/F J2 EXT Table Bulkhead
J2
2295953 CT Gantry
(Cable 2223729)
Table I/F J3 EXT Table Bulkhead
J3
2295956 CT Gantry
(Cable 2263663)
Table I/F J4 EXT Table Bulkhead
J4
2295958 CT Gantry
(Cable 2265683)
Table I/F J5 EXT Table Bulkhead
J5
2295959 CT Gantry
(Cable 2271059)
Table I/F J9 EXT Table Bulkhead
J9
2295960 CT Gantry
(Cable 2265683)
Table I/F J10 EXT Table Bulkhead
J10
2295961 CT Gantry
(Cable 2265683)
Ground Table Base ETC Backplane 2295969 CT Gantry Base
Ground ETC
Backplane
Table Base 2301800 Ground Bar on
Table Base
Base Axis Motor R J11 2309058 CT Gantry
(Cable 2323720)
Clutch R J12 2309059 CT Gantry
(Cable 2323726)
Pedals L.S.R. J13 2309064 Spare Cable
