GE HEALTHCARE
DIRECTION 2307224-100, REVISION 6DISCOVERY LS SYSTEM SERVICE MANUAL
Page 346 Appendix A - Illustrated Parts Breakdown
A.2.6 Cabling
Table A-6: Assembly 2290249 - Discovery LS Cabling Assembly
Item Part Number Description
0010 2287062 Legs Crossbeam
0040 2290093 Bulkhead Bracket Left
0050 2290094 Bulkhead Bracket Power
0060 2290095 Bulkhead Bracket Data
0020 2296528 Static Retractor Bracket
0030 2296529 Inner Retractor Bracket
0160 2296530 Outer Retractor Bracket
0190 HF00037125I Cable-Chain, 16 Links, Inner R
0200 HF000375200 Cable-Chain, 20 Links, Outer R, SR445075200A445075KM3
0070 HS004005016 Screw M-5, L = 16 mm Cap-Head
0090 HS004006010 Screw M-6, L = 10 mm Cap-Head
0080 HS004006020 Screw M-6, L = 20 mm Cap-Head
0210 HS006012040 Screw M-12, L = 40 mm Hex-Head
0220 HW00081200M Washer M12, ID = 13, OD = 37, T = 3, DIN9021
0100 HW00100005M Washer M-5, ID = 5.3, OD=10
0110 HW00100006M Washer M-6, ID = 6.4, OD = 12
0130 HW00800050M Washer Lock Spring M-5, OD=8.8
0140 HW00800060M Washer Lock Spring M-6, OD=
0230 HW00800120M Washer Lock Spring M-12, OD=
0170 XW025000201 Cable-Tie Mount, 14.9 x 9.5 x 9.9
0180 XW025000203 Cable-Tie Mount Screw, Hole No
