GE HEALTHCARE
DIRECTION 2307224-100, REVISION 6DISCOVERY LS SYSTEM SERVICE MANUAL
Chapter 10 - Electrical Connections Page 269
10.1.6 CT Gantry Cables
The cables that connect to the CT Gantry are Blue Coded.
10.1.6.1 CT Gantry Cables – Manual Table
Table 10-8: CT Gantry Cables (Manual Tables)
Cable Connector
Part
Number
Destination Notes
Scan Interlock J7 2271060 Console STC Backplane
Control J8 2266014 PDU STC Backplane
DAS Data Power Panel 2117848-2 Console J52 Fiber-Optic
High Voltage AC Power Panel 267644 CPDU
2347514 NGPDU
High Voltage DC Power Panel 2267642 CPDU
2347513 NGPDU
120 VAC Power Power Panel 2266880 CPDU J4 On Power Panel
2347377 NGPDU TS5
E-Stop/Sources
CT-PET
CT 1000 J1 2295382 PET Gantry
A37 J101
CT-PET LAN Power Panel J3 2295968 PET Gantry
A37 J102
Table I/F,
2271059
From GAN to Table
Retractor Side
2271059 To Cable
2295959
Power 120 VAC From GAN to Table
Retractor Side
2265683 To Cables
2309061,
2295958,
2295960
Covers to ETC From GAN to Table
Retractor Side
2263663 To Cable
2295956
Tilt Limit Switch From GAN to Table
Retractor Side
2268222 To Cable
2295953
LAN From GAN to Table
Retractor Side
2265881-2 To Cable
2295952
To Next Page
