GE H
EALTHCA
RE
D
IRECTION
2307224-100, R
EVISION
6D
ISCOVERY
LS S
YSTEM
S
ERVICE
M
ANUAL
Page 238
Chapter 7 - Gan
try
8.)
Refer to
Figure
7-
17
and
Fig
ure
7-18
. Fold the retracto
r and conn
ect the bracket to the legs
crossbeam using four 6 x 20 mm scr
ews.
Figure 7-17:
External and Intern
al Retractors Connected to Legs Crossbeam
Figure 7-
18:
Internal Retractor and Cables
Clips
Legs Crossbeam
Brackets
Length of
Protruding Cables
External Retractor
Internal Retractor
Internal Retractor
237
239
