Page 40 Chapter 1 - Preface

WARNING WARNINGS ARE USED TO IDENTIFY CONDITIONS OR ACTIONS FOR WHICH A SPECIFIC

HAZARD IS KNOWN TO EXIST, WHICH MAY CAUSE SEVERE PERSONAL INJURY, DEATH

OR SUBSTANTIAL PROPERTY DAMAGE IF THE INSTRUCTIONS ARE IGNORED.

CAUTION Cautions are used to identify conditions or actions for which a potential hazard may exist,

which will or can cause minor personal injury or property damage if the instructions are

ignored.

1.6.2 IEC Symbols

The system may have labels with one or more of the following symbols. These symbols indicate the

IEC standards to which the system conforms.

Symbol IEC Standard

Alternating Current

Protective Earthing Point

ON / Power

OFF / Power OFF

Input Power

Output Power

Functional Earth Ground

Warning, Caution - consult accompanying documents

Electrical Shock Hazard
