Chapter 11 - Replacement Parts Page 299
Item Part Number Description
FRU
Yes/No
Quantity
0010 2304631 Pulley for Motor Yes 2
0060 2304646 Shaft 2 Yes 1
0070 2304647 Belt Base Yes 1
0080 2304652 Pulley Shaft 4 Yes 1
0090 2304654 Key, 3.2 x 3.2 mm Yes 2
0110 2304666 Pulley, Base Axis Yes 2
00170 2305660 Belt Shaft Yes 1
00180 2306555 Lock Ring Yes 4
00190 2306556 Adjuster Leveling Pad Yes 4
0200 2306557 Leveling Pad Yes 4
0150 2309028 Motor Coupling Yes 1
0160 2309029 Cam Rail, Secondary Base Yes 1
B010279211 Motor, Servo (Not shown.) Yes 1
DG00030428B Clutch, Torque 240 (Not shown.) Yes 1
2309065 Remote Control, Secondary Base
(Not shown.)
Yes 1
2309062 Cable, Limit Switch and Clutch
(Not shown.)
Yes 1
2199586 Position Limit Switch (Not shown.) Yes 4
0310 2325772 KB Box Assembly Yes 1
0370 2309898 Spring for Table Belt Yes 2
0680 2315204 Spacer for Roller Cover Yes 1
Table 11-9: Secondary Base Components
