# Configure IP addresses of the interfaces on the CEs according to Figure 3-3. The configuration
procedure is not given here.
After the configuration, run the display ip vpn-instance verbose command on the PEs, and you
can see the configuration of the VPN instances. The PEs can ping the connected CEs
successfully.
NOTE
If multiple interfaces on a PE are bound to the same VPN, you must specify the source address when you
run the ping -vpn-instance command to ping the CE connected to the peer PE. That is, specify -a source-
ip-address in the ping -vpn-instance vpn-instance-name -a source-ip-address destination-address
command. Otherwise, the ping operation may fail.
Take PE1 and CE1 for example.
[PE1] display ip vpn-instance verbose
Total VPN-Instances configured : 2
VPN-Instance Name and ID : vpna, 1
Create date : 2008/11/24 16:28:27
Up time : 0 days, 00 hours, 11 minutes and 25 seconds
Route Distinguisher : 100:1
Export VPN Targets : 111:1
Import VPN Targets : 111:1
Label policy : label per route
The diffserv-mode Information is : uniform
The ttl-mode Information is : pipe
Interfaces : Vlanif10
VPN-Instance Name and ID : vpnb, 2
Create date : 2008/11/24 16:30:37
Up time : 0 days, 00 hours, 09 minutes and 15 seconds
Route Distinguisher : 100:2
Export VPN Targets : 222:2
Import VPN Targets : 222:2
Label policy : label per route
The diffserv-mode Information is : uniform
The ttl-mode Information is : pipe
Interfaces : Vlanif20
[PE1] ping -vpn-instance vpna 10.1.1.1
PING 10.1.1.1: 56 data bytes, press CTRL_C to break
Reply from 10.1.1.1: bytes=56 Sequence=1 ttl=255 time=5 ms
Reply from 10.1.1.1: bytes=56 Sequence=2 ttl=255 time=3 ms
Reply from 10.1.1.1: bytes=56 Sequence=3 ttl=255 time=3 ms
Reply from 10.1.1.1: bytes=56 Sequence=4 ttl=255 time=3 ms
Reply from 10.1.1.1: bytes=56 Sequence=5 ttl=255 time=16 ms
--- 10.1.1.1 ping statistics ---
5 packet(s) transmitted
5 packet(s) received
0.00% packet loss
round-trip min/avg/max = 3/6/16 ms
Step 4 Set up EBGP peer relation between the PE and the CE and import VPN routes.
# Configure CE1.
[CE1] bgp 65410
[CE1-bgp] peer 10.1.1.2 as-number 100
[CE1-bgp] import-route direct
NOTE
The configuration procedures of CE2, CE3 and CE4 are similar to the configuration procedure of CE1 and
are not mentioned here.
# Configure PE1.
3 BGP/MPLS IP VPN Configuration
Quidway S9300 Terabit Routing Switch
Configuration Guide - VPN
3-62 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 03 (2009-08-20)
