Intel® Server D50DNP Family Integration and Service Guide
105
Feature Description
I/O Ports
• One USB 3.0 port
• One I/O breakout cable, supporting the following:
o Two USB 3.0 port connectors (dual-stack)
o One VGA connector
o One serial port connector compliant with the Advanced Technology pinout specifications.
Note: The I/O breakout cable is available as an accessory option (iPC AXXCONNTDBG).
Networking
• One external 10GBASE-T Ethernet port (RJ45)
•
One external 1000BASE-T Ethernet port (RJ45) dedicated to server management
LEDs
• Module status
•
Module ID
Buttons
• Power
• Module ID
• Module cold reset
•
Non-maskable interrupt (NMI)
Expansion Options
Riser Slots
Two riser slots are available to connect PCIe add-in cards and storage devices.
See module specific information for riser options.
Supported Onboard Connectors and Headers
Mini Cool Edge I/O
(MCIO*) PCIe* Interface
Support
• Two MCIO connectors each with x16 PCIe 5.0 lanes are routed from CPU 0
• Four MCIO connectors each with x16 PCIe 5.0 lanes are routed from CPU 1
Security and Serviceability
Security
Supported security technologies:
• Intel® Platform Firmware Resilience (Intel® PFR) technology 3.0
• Intel® Total Memory Encryption – Multi-Key (Intel® TME-MK) Technology
• Intel® Software Guard Extensions (Intel® SGX) Technology
• Intel® Converged Boot Guard and Trusted Execution (Intel® CBnT) Technology
• Trusted platform module 2.0 (China version) AXXTPMCHNE8 (accessory option)
•
Trusted platform module 2.0 (rest of the world) AXXTPMENC9 (accessory option)
Server Management
• Integrated Baseboard Management Controller (BMC) based on the ASPEED* AST2600 Advanced
PCIe* Graphics and Remote Management Processor
• Compliant with the Intelligent Platform Management Interface (IPMI) 2.0
• Compliant with Redfish*
• Supports OpenBMC
• Supports Intel® Data Center Manager (Intel® DCM)
• Supports Intel® Server Debug and Provisioning Tool (Intel® SDP Tool)
• One external 1000BASE-T Ethernet port (RJ45) dedicated to server management
• Intel® Light-Guided Diagnostics included with onboard LEDs
Onboard Configuration
and Service Jumpers
• BIOS load defaults
• BIOS password clear
• Intel® Management Engine (Intel® ME) firmware force update
• BIOS SVN downgrade
• BMC SVN downgrade
BIOS
• Unified Extensible Firmware Interface (UEFI)-based BIOS (legacy boot is not supported)
Module Support
• D50DNP1MHCPAC
• D50DNP1MHEVAC
• D50DNP1MHCPLC
• D50DNP2MHSVAC
• D50DNP1MFALLC
• D50DNP2MFALAC
