Table 9. Intel® Server Chassis / Intel® Server System D50DNP Feature Set
Feature
Description
Chassis FC2HLC30W0 Chassis FC2FLC30W0 Chassis FC2HAC27W0 Chassis FC2FAC27W0
Chassis
Definition
FC2000 half-width
configuration, liquid
cooled
FC2000 full-width
configuration, liquid
cooled
FC2000 half-width
configuration, air cooled
FC2000 full-width
configuration, air cooled
Chassis Type
2U, rack-mount, multi-module
2U rack-mount, single
module
Chassis
Dimensions
865 x 442 x 86.8 mm
Packaging
Dimensions
1192 x 758 x 317 mm (L x W x H)
Supported
Intel® D50DNP
Modules
Up to four 1U
half-width compute
modules (liquid
cooled)
Up to two 1U Intel®
Data Center GPU Max
Series Accelerator full-
width modules (liquid
cooled)
• Up to four 1U
half-width modules (air
cooled)
• One 2U half-width
module and two 1U
half-width modules (air
cooled)
• Up to two 2U half-width
modules (air cooled)
• One PCIe accelerator
module 2U full-width
(air cooled)
Cooling
Liquid-cooled configurations:
• Liquid-cooling loop (per module)
• Liquid-cooling plumbing connections on the back
of the chassis
• Two 40 x 40 x 40 mm fans
Air-cooled configurations:
• Eight dual-rotor hot-swap system fans with support
for fan redundancy
o Four 60 x 60 x 56 mm fans
o Important Note: Only install 60-mm system fans
that are designed for the Intel® Server Chassis
D50DNP (FCXX60MMACFAN). Do not install 60-
mm system fans from previous product
generations.
o Four 40 x 40 x 40 mm fans
• One 40-mm fan per installed power supply unit
(PSU)
Power
Supports four 3000 W AC power supplies with
power redundancy (dependent on system
configuration). PSUs are sold separately.
Supports four 2700 W AC power supplies with power
redundancy (dependent on system configuration).
PSUs are sold separately.
Rack Mount Kit
(FCXXRAILKIT)
• Tool-less installation
• Fixed position
Note: Rack mount kit is included with the chassis.
Serviceability
Modular chassis features for simplified serviceability:
• Fully independent Intel® D50DNP Modules
• Hot-swap power supplies
• Hot-swap system fans
•
Hot-swap U.2 solid state drive (SSD) storage (2U Intel® D50DNP Modules)
Operating
Temperature
10–35°C ambient temperature
Server
Management
Optional Ethernet Management Port (EMP) that allows to aggregate management ports on each module and
daisy-chain chassis to minimize number of cables.
