2. L6 Integrated System Essential System Component
Installation
The Intel® D50DNP Modules are offered with different levels of system integration. Modules that are not
power-on ready are identified as L6 integrated modules. L6 modules require essential components (sold
separately) to be installed. If your Intel® D50DNP Module did not come preinstalled with any of the following
components, follow the procedures in this chapter:
• 2 processors – 4
th
Gen Intel® Xeon® Scalable processors or Intel® Xeon® CPU Max Series processors
• Memory:
o Up to 16 DDR5 DIMMs or
o Up to 8 DDR5, plus 8 Intel® Optane™ persistent memory (PMem) 300 series DIMMs (air-cooled
configurations only).
• Liquid-cooling Loop (liquid-cooled configurations only)
• Power supplies
If your Intel® D50DNP Module came preinstalled with all the components listed earlier, skip this chapter and
go to Chapter 3 for installation procedures associated with all other system options and accessories.
To complete the L6 integration of the Intel® Server D50DNP to be power-on ready, a chassis from the Intel®
Server Chassis FC2000 v2 family is required to contain the L6 integrated modules. The chassis for L6
systems is sold separately. The 2700 W (air cooled) or 3000 W (liquid cooled) power supply units are also
sold separately.
Each module within a system is operating independently from the others. However, the modules share
common chassis resources like power and cooling. Table 2 describes the different ways that an Intel® Server
System D50DNP can be configured.
For additional information regarding configuration options, see the Intel® Server D50DNP Family
Configuration Guide.
Table 2. Intel® D50DNP Modules
Module Type iPC Height Width Cooling
Maximum Processor
Thermal Design
Power (TDP)
Modules per
Chassis
Compute
D50DNP1MHCPAC
1U Half width
Air cooled
250 W
Up to four
D50DNP1MHEVAC 270 W
D50DNP1MHCPLC Liquid cooled 350 W
Management D50DNP2MHSVAC 2U Half width Air cooled 350 W Up to two
Intel® Data
Center GPU Max
Series
Accelerator
D50DNP1MFALLC 1U Full width Liquid cooled 350 W Up to two
PCIe* Accelerator D50DNP2MFALAC 2U Full width Air cooled 350 W One
