Diagnostic Information 2-25
4023-001
246 Paper Jam
Check Tray 4
Paper is jammed inside
the 2500-sheet A4
drawer (LCC).
Open the LCC drawer to
access the jam area.
Check sensor and actuator
for PPSO, RSEN. Replace
the LCC main board PWB-
A if necessary. Replace the
printer main engine board
PWB-A if necessary. Go to
“Paper Feed LCC
(2500-Sheet Tray 4)
Service Check” on
page 2-51
.
247 Paper Jam
Open Door F
Paper is jammed inside
the 2500-sheet A4
drawer (LCC).
Open side door F to
access the jam area. If
jam is not located by
opening the side door,
open LCC paper drawer.
Check sensors and
actuators for PPSO,
RSEN, and S1. Replace
the LCC main board PWB-
A if necessary. Replace the
printer main engine board
PWB-A if necessary. Go to
“Paper Feed LCC
(2500-Sheet Tray 4)
Service Check” on
page 2-51
.
251 Paper Jam
Open Door C
Paper is jammed in the
vertical transport
section.
• Open tray 2 through 4
side doors (doors
D,E,F) to access the
paper jam.
Check paper sensor and
actuator in tray 2 (S3), tray
3 (S3), tray 4 (PPSO,
RSEN). If necessary,
replace main board PWB-A
located in failing option.
Replace the printer main
engine board PWB-A if
necessary.
Go to:
•
“Paper Feed Pickup
Tray 2&3 (500-Sheet)
Service Check” on
page 2-44
.
•
“Paper Feed LCC
(2500-Sheet Tray 4)
Service Check” on
page 2-51
.
Message Description Action
